Performance
Frequency Range (-10 dB)
45 Hz -138 Hz
Maximum Peak SPL at 1 m
134 dB
Electronics and Connectors
Nominal Amplifier Power (continuous)
1000 W
Nominal Amplifier Power (peak)
2000 W
Input Type
Balanced
Input Impedance
20 kohms
Input Sensitivity
1.95 V (+8 dBu)
Audio Signal Input Connector
2 x Female XLR
Audio Signal Loop Thru Connector
2 x Male XLR
AC Input Connector
powerCon NAC3FCA
AC Output Connector
powerCON NAC3FCB
Current Draw 230 V / 115 V
2.0 A/-
Enclosure
Enclosure Construction
Birch Plywood
Enclosure Geometry
Rectangular
Rigging
M10 Rigging Points
Finish
ISO-flex Paint
Color
White
Dimensions ( H x W x D )
515 x 465 x 585 mm 20,3 x 18,3 x 23,0 in
Net Weight
31,0 kg ( 68,3 lb )
Components
LF Driver
15LXN
Shipping
Carton Dimensions ( H x W x D)
580 x 510 x 632 mm 22,8 x 20,1 x 24,9 in
Shipping Weight
37,0 kg ( 81,6 lb )
