WLA-210A Wharfedale Pro

Dual 10″ active line array element with EVO-Fold

  • Dual 10″ active
  • 133 dB Max SPL @ 1 meter
  • 15 mm / 18 mm Birch plywood construction
  • 100° x 10° dispersion
  • 700 W LF + 100 W HF Continuous
  • 1400 W LF + 200 W HF Peak
  • 8 x DSP presets including FIR
SKU: WLA-210A Categories: , , Tag: Brand:

Description

Product description

WLA-210A is a dual 10″ active line array system that redefines clarity, control, and output power through advanced acoustic and digital engineering. Designed and engineered in the UK, it combines innovative hardware design with intelligent DSP processing, making it ideal for both touring and fixed installations.

At its core are two custom Wharfedale Pro 10″ LF drivers and a 3.0″ HF compression driver coupled to the acclaimed EVO-Fold waveguide. Paired with precision-engineered phase plugs, this design ensures a smooth, coherent response across the listening field with minimal phase interference.

An internal 800 W continuous amplifier drives the system, supported by 8 integrated DSP presets with FIR filtering, allowing fast and accurate configuration for any array size or venue. Remote DSP control via RS485 offers full GUI-based tuning and monitoring of every element in the system.

Delivering up to 133 dB max SPL @ 1 m, the WLA-210A combines power, precision, and flexibility—setting a new benchmark for compact active line array performance.

Specifications

Active or Passive
Active
System Type
Array Element
Configuration
2-way
System Continuous Power
LF: 700 W / HF: 100 W
System Peak Power
LF: 1400 W / HF: 200 W
Max SPL @ 1m
133 dB
Freq Response (+/-3 dB)
55 Hz – 20 KHz
Freq Range (-10 dB)
50 Hz – 20 KHz
Bi-amp Mode Switch
No
Bluetooth
No
IP Certification
None
Driver Brand
Wharfedale Pro
LF Driver Size
2 x 10"
LF Magnet Material
Ferrite
LF Frame Material
Aluminium
LF Voice Coil Size
2.5”
HF Driver Type
Compression Driver
HF Voice Coil Size
3”
HF Diaphragm Material
Titanium
HF Exit Size
1.4″
HF Power (RE:AES2-2012)
90 W
HF Rated Impedance
8 Ω
Preset Library
No
Input Connector
Balanced Socket XLR
Waveguide Type
EVO-Fold
Enclosure Material
Birch Plywood
Grille Material and Finish
Steel
Finish
Black Tough-Tone
Handles
4
Deployment
Flying, Ground
Pole Mount
None
Brackets Included
Yes
Rigging
Yes
Integral Rigging
3 Points
Nominal Coverage (H x V)
100° x System dependant
Sensitivity 2.83 V / 1 m
101 dB
Crossover Frequency
1.5 KHz
Amplifier design
Class D
Driver Protection
Independent LF/ HF RMS, Peak Limiters and DC
Thermal Protection
Amplifier Shut Down. Auto Reset
DC and Short Protection
Yes
Signal Processing
DSP Based, 8 FIR Presets
Power On Protection
Power switch on/off mute
Low Line Voltage Shut Down
60% Nominal Line Voltage
Limiter Indicator
Red LED
Signal Indicator
Green LED
Power/Active Indicator
White LED
Find Function Indicator
Blue LED
Active loudspeaker Input Impedance
Balanced: 10 KΩ
Link Connector
Balanced Pin XLR
Input sensitivity
+4 dBu
Max input level
+18 dBu
Update
USB Type B
Network (RS485)
RJ45
AC Input Connector
powerCON
AC Loop Through Connector
powerCON
Main Power
AC 100-120 V~ and 220-240 V~, 50/60 Hz Automatic
Power Supply
High Efficiency Switching Mode Power Supply
Included Accessory
User Manual, WLA-RH4 Rain hood
Unpacked - Front Height (mm)
314
Unpacked - Rear Height (mm)
190
Unpacked - Width Front (mm)
760
Unpacked - Width Rear (mm)
760
Unpacked - Depth (mm)
503
Packed - Height (mm)
870
Packed - Width Front (mm)
410
Packed - Width Rear (mm)
410
Packed - Depth (mm)
600
Weight - Nett (kg)
40.44
Weight - Gross (kg)
44.32
