S16 Behringer

RM2,705.00

I/O Box with 16 Remote-Controllable Midas Preamps, 8 Outputs and AES50 Networking featuring Klark Teknik SuperMAC Technology

16 Midas-designed, fully programmable mic preamps for audiophile sound quality
8 analogue, servo-balanced XLR outputs
AES50 network ports featuring Klark Teknik’s SuperMAC networking capability for ultra-low jitter and latency
ULTRANET connectivity for Behringer’s P16 personal monitoring system
Digital audio and control connectivity for Turbosound speaker systems with ULTRANET networking capability
Dual AES50 ports for cascading additional S16, SD16 or SD8 stageboxes— no merger or router required
Precise LED metering plus 7-segment displays for signal control on stage
Dual ADAT outputs providing 16-channel digital output on two optical TOSLINK connectors
Phones output assignable to any of the inputs/outputs for on-stage monitoring
MIDI In/Out for bi-directional communication between Behringer X32 Series console and on-stage MIDI devices
Remote operation via shielded CAT5e cable up to 330 ft / 100 m length
USB connector for system updates via PC
Planet Earth switching power supply for maximum flexibility (100 – 240 V~), noise-free audio, superior transient response plus low power consumption for energy saving
Built like a tank yet compact, all-steel 2U rack-mount chassis

SKU: S16 Categories: Professional Sound, Speakers, Stage Monitors Tag: Behringer Brand: Behringer

Description

Product description

Digital mixing has revolutionized virtually everything in the live-entertainment production workflow. Now we have come up with the perfect solution for connecting the onstage talent with your Front of House (FOH) console, and the rest of the world – the ultra-cool and ultra-affordable S16 Digital Snake! The S16 provides 16 Midas-designed remote-controllable mic preamps, plus 8 balanced analog XLR returns at the stage end – and all it takes is a single Cat 5e cable. While Klark Teknik, the industry-leader in high-end digital audio processing, invented the SuperMAC technology that made it all possible – our superb scale of production makes the S16 so very affordable.

General

Compatibility

Behringer X-Series

Microphone Input

Design: MidasTHD + Noise, 20 dB Gain, 0 dBu Out: < 0.006% A-WeightedInput Impedance XLR, Unbalanced / Balanced: 5 Kilohms / 10 KilohmsNon Clip Maximum Input Level, XLR: +23 dBuPhantom Power, Switchable per Input: 48 VEquivalent Input Noise Level, XLR (Input Shorted): -128 dBuCMRR, XLR, at 20 dB Gain (Typical): > 70 dBCMRR, XLR, at 40 dB Gain: > 80 dB

Performance

Frequency Range, at 48 kHz Sample Rate, (0 to -1 dB): 10 Hz to 22 kHzDynamic Range, Analog In to Analog Out (Typical): 106 dBA/D Dynamic Range, Preamp and Converter (Typical): 109 dBD/A Dynamic Range, Converter and Output: 108 dBCrosstalk Rejection at 1 kHz, Adjacent Channels: 100 dBOutput Level, XLR, (Nominal/Maximum): +4 dBu / +21 dBuOutput Impedance, XLR, Unbalanced / Balanced: 75 OhmsPhones Output Impedance / Level: 40 Ohms / +25 dBm (Mono)Residual Noise Level, XLR and TRS: -87 dBu A-Weighted

Panel Type

Single-Color LED

Touchscreen

Indicators

Display: 4-Digit, 7-Segment, LEDFront status LEDsAES50-A, Red/GreenAES50-B, Red/GreenHA Locked, RedSN Master, GreenSplitter, OrangeOut +16, OrangeOut +8, OrangeMeter: Sig, -30, -18, -12, -9, -6, -3 dB, ClipRear Panel: Splitter Mode, Orange

Inputs/Outputs

USB I/O

1 x USB-B Female Input

Audio I/O

16x XLR 3-Pin Line/Mic Input8x XLR 3-Pin Line Output1x 1/4" TRS Headphone Output

Digital I/O

2 x AES50 Ports, SuperMAC, NEUTRIK etherCON1 x P-16 Connector, Ultranet (No Power Supplied)2 x 5-Pin DIN MIDI (Inputs/Outputs)2 x ADAT Toslink Outputs (2 x 8 Ch)

Power

Power Source

AC Input (Included)

AC Input Power

100 to 240 VAC, 50 / 60 Hz

Power Consumption

45 W

Physical

Color

Gray

Environmental Resistance

Dimensions

19 x 8.9 x 3.5" / 48.3 x 22.6 x 8.9 cm

Weight

10.4 lb / 4.7 kg

Package Weight

12.62 lb

Box Dimensions (LxWxH)

21.75 x 12 x 6"

Specifications

General

Display

Specification Notes

Line 01

Inputs/Outputs

Line 02

Power

Line 03

Physical

Line 04

Packaging Info
