TS15S Alto

RM3,850.00

2500-WATT POWERED SUBWOOFER WITH A 15″ DRIVER

  • 2500W peak power output
  • High-efficiency Class D amplifier
  • Transducer: 15-inch driver with 3-inch high-temperature voice coil
  • (2) XLR+1/4-inch combo inputs
  • (2) XLR thru outputs for linking
  • User-selectable EQ tunings (Off, Live, DJ)
  • Phase Alignment selector switch (0°/90°/180°/270°)
  • Rugged, internally-braced front-ported MDF cabinet with integrated 36 mm pole socket
  • Mark-resistant splatter-spray finish always looks good, even with heavy use
  • Electronic clip, thermal and transducer overdrive protection
  • Designed and tuned in the USA
SKU: TS15S Categories: , , Tag: Brand:

Description

Product description

The best performances need the best in sound reinforcement at all ends of the sonic spectrum. For tight, punchy low-end look no further than the Alto Professional TS15S powered subwoofer. When added to your full-range speaker setup, the TS15S subwoofer delivers powerful but controlled low-end presence to your PA configuration for a full and complete listening experience for the modern public music space. With a powered subwoofer, any musical performance will take a giant leap into the realm of tonal balance with the perfect blend of hi, mid, and extended low-end frequencies.

Specifications

Output Power
2500 W peak @ 4 Ω
Transducer Low
15" (381 mm) woofer; 3" (76.2 mm) high-temperature voice coil
Frequency Response
36 Hz – 110 Hz (-3 dB)
Frequency Range
31 Hz – 123 Hz (-10 dB)
Maximum SPL
132 dB (@ 1 m)
Connections
(2) XLR+1/4" (6.35 mm) inputs; (2) XLR outputs; (1) IEC power cable input
External Controls
Volume control, signal/clip limiter with LED, speaker use button, proximity button, power switch with LED
Electronic Protections
Electronic clip, thermal and transducer overdrive protection
Enclosure
Internally braced MDF cabinet; 36 mm mounting pole socket on top panel
Caster Insert Thread Gauge
M6 x 1.00 mm

Power

Connection
Standard IEC cable
Input Voltage
100-120, 50/60 Hz; 220-240 VAC 50/60 Hz
Consumption
1600W
Fuse
100-120V, T15AL AC250V; 220-240V, T8AL AC250V
Dimensions (height x width x depth)
21.3" x 20.6" x 24.7" / 541 x 523 x 627 mm
Weight
87.1 lbs. / 39.51 kg
