MS8000 Behringer

RM293.00

Ultra-Flexible 8-Channel Microphone Splitter

Ultra-low noise 8 in/16 out microphone splitter
Each channel features Direct and Link outputs
Output ground lift switch per channel
Flexible input link switches
Phantom power link to Direct Output

SKU: MS8000 Category: Professional Sound Tag: Behringer Brand: Behringer

Description

Product description

When it comes to connectivity on the stage or in the studio, you can never have too much – and that’s where the ultra-flexible MS8000 8-Channel Microphone Splitter makes all the difference. The MS8000 provides the ideal solution for live and recording musicians who need to send signals to multiple locations, including mixing and recording consoles, In-Ear-Monitors (IEMs), floor wedges, broadcast trucks and much more. With 8 Inputs and 16 Outputs, the MS8000 easily connects you to the Front of House (FOH) console – and sends duplicate signals to your choice of destination devices.

General

System

Frequency Response: 30 Hz to 30 kHz (±0.5 dB at +4 dBu)THD + N (Distortion): 0.02% @ 1 kHz, Input Level +4 dBuSignal-to-Noise Ratio: 104 dBuCMRR: >80 dB, TypicalInsertion Loss: +8 dB at 100 Kilohms, -5 dB at 600 Ohms Power Requirement: None (Passive)

Audio Inputs

Connectors: 8 x XLRImpedance: 1 Kilohm, BalancedMaximum Input Level: 30 dBu at 1 kHzControls: Link, Lift/Ground

Audio Outputs

Link Connectors: 8 x XLR, Parallel to InputsDirect Out Connectors: 8 x XLRVoltage Transformation Ratio: 1 : 1.2Impedance: 2.7 Kilohms, BalancedMaximum Output Level: 38 dBu at 1 kHz

Physical

Mounting

Side: 2x Rack Ears

Color

Black

Environmental Resistance

Dimensions

19 x 2.6 x 1.7" / 483 x 65 x 44 mm

Weight

2.4 lb / 1.1 kg

Package Weight

3.325 lb

Box Dimensions (LxWxH)

21 x 5.1 x 3.5"

Specification Notes

Line 01

General

Line 02

Physical

Line 03

Packaging Info
