Delta-X18B Wharfedale Pro

RM3,020.00

DELTA-X18B

  • 18″ Subwoofer
  • 4.0″ voice coil
  • 800 watts AES (RMS)
  • 1600 watts Programme
  • 3200 watts Peak
  • 134 dB Max SPL @ 1 meter
SKU: Delta-X18B Categories: , , Tag: Brand:

Description

Product description

18″ Subwoofer with bi-amp functionality

Delta-X18B is a high-powered 18-inch passive subwoofer built to deliver deep, authoritative low-end for live sound and fixed installations.

Its enclosure is crafted from 18 mm birch plywood and finished in our durable Tough-Tone paint, ensuring strength and resilience for touring and repeated use.

Designed to extend the performance of the Delta-X full-range cabinets, the rear panel offers connectivity that allows easy integration into either passive or bi-amped system configurations.

With 800 W continuous power handling (up to 3,200 W peak) and a maximum SPL of 134 dB, the Delta-X18B adds serious depth and impact to any setup. A Wharfedale Pro custom LF driver, mounted in the optimised cabinet, delivers tight, punchy bass that stays controlled even at high output levels.

Equipped with a 35 mm pole socket and robust side handles, the Delta-X18B is practical to deploy while bringing heavyweight low-frequency performance to the Delta-X family.

Specifications

Active or Passive
Passive
System Type
Subwoofer
Configuration
Bass-reflex
System Continuous Power
800 W
System Programme Power
1600 W
System Peak Power
3200 W
Max SPL @ 1m
134 dB (Half Space)
Freq Response (+/-3 dB)
38 Hz -1.5 kHz (Bi-amp)
Freq Range (-10 dB)
30 Hz - 150 Hz
Bi-amp Mode Switch
Yes
IP Certification
None
Driver Brand
Wharfedale Pro
LF Driver Size
18"
LF Voice Coil Size
4"
LF Rated Impedance
8 Ω
LF Power (RE:AES2-2012)
800 W
Preset Library
Yes
Input Connector
2 x 4 Pole Speaker Connector
Enclosure Material
Birch Plywood
Grille Material and Finish
Steel Black
Finish
Black Tough-Tone
Handles
2
Deployment
Ground
Pole Mount
35 mm
Brackets Included
No
Rigging
No
Sensitivity 2.83 V / 1 m
99 dB
System Rated Impedance
8 Ω
Recommended HPF = BW 18 dB/OCT.
30 Hz
Transformer (T)
No
EQ Type
None
Included Accessory
User Manual
Unpacked - Height (mm)
539
Unpacked - Width Front (mm)
539
Unpacked - Width Rear (mm)
539
Unpacked - Depth (mm)
650
Packed - Height (mm)
638
Packed - Width Front (mm)
733
Packed - Width Rear (mm)
733
Packed - Depth (mm)
615
Weight - Nett (kg)
37.3
Weight - Gross (kg)
42.6
