CX2310 V2 Behringer

RM440.00

High-Precision Stereo 2-Way/Mono 3-Way Crossover with Subwoofer Output

Professional stereo 2-way/mono 3-way crossover featuring state-of-the-art Linkwitz-Riley filters with 24 dB/octave
Additional subwoofer output with independent Frequency control
Absolutely flat summed amplitude response, zero phase difference
Individual output Gain controls for all bands
Individual output Mute switches for easy band adjustment
Individual Phase reverse switches for instant phase correction
Switchable 25 Hz Low cut filter on each input for low-frequency driver protection
Servo-balanced and gold-plated XLR connectors for all inputs and outputs
Ultra-high precision potentiometers for ultimate accuracy and repeatability
Illuminated switches for secure operation in dark stage environments
Internal switch-mode power supply (100 – 240 V~) for noise-free audio and low power consumption

SKU: CX2310 V2 Categories: Professional Sound, Speakers, Subwoofer Tag: Behringer Brand: Behringer

Description

Product description

The CX2310 stereo 2-way/mono 3-way crossover provides amazing-accurate audio frequency separation, thanks to its state-of-the-art circuitry, superior-grade components, ultra low-noise op amps and balanced I/O connectivity. Additionally, the CX2310 features an independently-adjustable Subwoofer Output, effectively providing an extra low-frequency band with a control range from 10 – 235 Hz. By using 1% metal film resistors, along with other extremely tight-tolerance components, the CX2310 is able to guarantee surgically-precise frequency selection with incredibly-low thermal noise. Put simply, the easy-to-use SUPER-X PRO CX2310 is one of the best-sounding crossovers in its class!

Audio Inputs

Type

XLR, electronically servo-balanced, HF filtered

Impedance

52 kΩ balanced, 26 kΩ unbalanced

Max. input level

+22 dBu, balanced or unbalanced

CMRR

Typically >60 dB @ 1 kHz

Audio Outputs

Type

XLR, electronically servo-balanced, HF filtered

Max. output level

+21 dBu, balanced or unbalanced

Performance

Bandwidth

20 Hz to 20 kHz, +0/- 0.5 dB

Frequency response

10 Hz to 60 kHz, +0/- 3 dB

Signal to noise

Ref: +4 dBu, 20 Hz to 20 kHz, unweighted

Low output

Stereo-Mode

>97 dB

Mono-Mode

>97 dB

Mid output

>98 dB

High output

>95 dB>94 dB

Subwoofer output

>97 dB>97 dB

Interchannel crosstalk

High to low:

Crossover

Filter-Type

Linkwitz-Riley, 24 dB/octave, state-variable

Mono mode X-Over frequency columns

x1 / x10

Mono Low/High

x1: 44 Hz to 930 Hz; x10: 440 Hz to 9.3 kHz

Mono Low/Mid

x1: 44 Hz to 930 Hz; x10: 440 Hz to 9.3 kHz

Mono Mid/High

x1: 44 Hz to 930 Hz; x10: 440 Hz to 9.3 kHz

Stereo mode X-Over frequency columns

x1 / x10

Stereo Low/High

x1: 44 Hz to 930 Hz; x10: 440 Hz to 9.3 kHz

Subwoofer X-Over frequencies

10 Hz to 215 Hz (-3 dB)

Low Cut Filter

Low cut filter frequency 25 Hz (-3 dB) 12 dB per octave

Power Supply

Switch-mode autorange power supply

100-240 V ~50/60 Hz

Power consumption

10 W

Mains connection

Standard IEC connector

Physical/Weight

Dimensions (H x W x D) 44 x 483 x 147 mm (1.7 x 19 x 5.8")

Weight

1.6 kg (3.5 lbs)
