XC-44N Wharfedale Pro

RM6,000.00

Maximise and Protect, Dante ® connectivity.

  • RMS Compressors and Peak Limiters.
  • Dual band Dynamic EQ stage on Inputs.
  • 96 KHz sampling frequency
  • PC Software control
  • USB, Ethernet and RS485
SKU: XC-44N Categories: , , Tag: Brand:

Description

Product description

XC-44N is a 4-in / 4-out system management controller delivering precise DSP control, advanced loudspeaker protection, and optimised performance for professional audio systems.

Built on the same DSP platform as our DP-F and DP-N amplifier ranges, XC-44N offers seamless integration and full file compatibility across the Wharfedale Pro ecosystem. Its powerful processing engine includes comprehensive FIR filters, advanced dynamics tools, and a full library of Wharfedale Pro loudspeaker presets for instant, reliable system tuning.

With analogue and AES/EBU inputs plus Dante(r) connectivity for networked audio integration, XC-44N provides maximum flexibility for live sound and installation setups. Controlled via our DSP Controller software, it allows detailed configuration and monitoring from a single, intuitive interface.

Featuring robust construction and locking XLR connectors, XC-44N combines professional-grade precision with the versatility required for any modern sound system.

Specifications

Inputs
4
Outputs
4
Input Type
Analog, AES/EBU, Dante ®
Controller Data Connection
Dante®
Input Connections
Locking XLR Input Connectors
Output Connections
XLR
Input Impedance
20 kΩ（Balanced), 10 kΩ（Unbalanced)
Output Impedance
600 Ω
Max Input Level
+20 dBu
Max Output Level
+20 dBu
Frequency Response
typical:+0, -1 dB(0 dB,20 Hz-20 kHz)
FIR
Yes
SNR
>105 dB（A weighted）
User Presets
Yes
Display Type
1.9-inch colour LCD display screen
Password Protected
Yes
Main Power
100 VAC - 240 VAC wide voltage range
Included Accessory
Power Cable, User Manual, Rubber Feet
Unpacked - Height (mm)
45
Unpacked - Width Front (mm)
483
Unpacked - Width Rear (mm)
483
Unpacked - Depth (mm)
160
Packed - Height (mm)
95
Packed - Width Front (mm)
540
Packed - Width Rear (mm)
540
Packed - Depth (mm)
270
Weight - Nett (kg)
2.2
Weight - Gross (kg)
2.8
