X18 Behringer

RM2,470.00

18-Channel, 12-Bus Digital Mixer for iPad/Android Tablets with 16 Programmable Midas Preamps, Integrated WiFi Module and Multi-Channel USB Audio Interface

  • iPad/Android tablet controlled 18-input digital mixer for studio and live applications
  • 16 award-winning Midas-designed, fully programmable mic preamps for audiophile sound quality
  • Built-In Tri-Mode WiFi router for direct operation no need for external routers
  • 18 x 18 channel, bidirectional USB interface for direct recording on iPad etc.
  • Revolutionary Dugan style Auto-Mixing automatically manages microphone gain sharing
  • Award-winning X32 effects rack featuring 4 stereo FX slots including high-end simulations such as Lexicon 480L and PCM70, EMT250 and Quantec QRS etc.
  • 100-band Real Time Analyzer (RTA) for all channel and bus EQ’s
  • ULTRANET connectivity for Behringer’s P-16 Personal Monitoring System
  • Ultra-wide tray suitable for almost all tablets, iPads and even mini notebooks
  • 6 aux and main LR buses with inserts, full dynamics processing and 6-band parametric or 31-band graphic EQ
  • 6 TRS aux outputs and 2 XLR main outputs plus stereo RCA output and phones connectors
  • 40-Bit floating-point DSP features “unlimited” dynamic range with no internal overload and near-zero overall latency
  • Free iOS, Android and PC/Mac/Linux apps available for remote operation via Ethernet, LAN or WiFi
  • MIDI In/Out allows controlling the mixer via MIDI equipment (incl. Mackie Control protocol) or for use as a USB MIDI interface (future firmware)
  • Future firmware updates, incl. new FX “Plug Ins”, downloadable from behringer.com free of charge
  • Internal switch-mode power supply for noise-free audio and low power consumption
SKU: X18 Categories: , , Tag: Brand:

Description

Product description

The BEHRINGER X32 completely changed the game by rethinking what is possible from a digital mixer – and over 100,000 users are enjoying the results. Now, that same technology has been incorporated into a small, but incredibly powerful, rack-mountable mixer that will forever change both the way you record – and the way you play live music. The revolutionary X18 is a powerhouse 18 input/12 bus digital mixer that also serves as the launch pad for your favorite computer tablet – including iPad and Android tablets. It is ideally suited for both live and studio applications, thanks to its 16 award-winning MIDAS-designed mic preamps, convenient integrated WiFi module for wireless control – and a lightning-fast, bidirectional USB Audio Interface.

The freedom to move around and manipulate all parameters of your mix with the free iOS, Android and PC apps lets you dial in the perfect sound from anywhere in the venue – or the tracking room! Advanced engineering and meticulous design deliver stellar sonic performance at an extremely affordable price – changing the game once again.

Specifications

Max I/O Capacity
18x Input / 12x Output
Number of Analog Input Channels
16 (16 Mono / 0 Stereo)
Number of Mic Preamps
16
Number of Analog Output Channels
10
Faders & Level Adjustment
No
Analog Inputs
16x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line/Hi-Z Input1x Stereo RCA Coaxial Unbalanced Line Input (1 Stereo Pair)
Analog Outputs
2x XLR Main/Bus Output6x 1/4" Aux Send1x Stereo RCA Control Room/Monitor Output1x 1/4" Headphone OutputShow More
Digital I/O
1x RJ45 Ethernet (Control, 1 Gb/s)1x RJ45 Ultranet (I/O)
USB I/O
USB-BUSB-A
Wireless
No
Rack Mountable
No

Mixer

Max I/O Capacity
18x Input / 12x Output
Number of Analog Input Channels
16 (16 Mono / 0 Stereo)
Number of Mic Preamps
16
Number of Analog Output Channels
10
Mix Routing
12x Stereo Bus
Groups
4x DCA Group4x Mute Group
Presets
64x Scene
Faders & Level Adjustment
No

Signal Processing

Gain/Trim Range
Mic:0 dB to +72 dB
Input Polarity
Normal/Reverse
Dynamic Processing
Input Channels:Compressor, Limiter, Soft Limiter, Gate
EQ
Input Channels:4-Band EQOutput Buses, Outputs:6-Band EQ
Graphic EQ
31-Band 1/3 Octave
Solo/Mute
No
Audio Delay
No
Automatic Mic Mixing
Yes
Sample Rates
44.1 / 48 kHz
Bit Depth
AD/DA Conversion:24-Bit

Performance

Frequency Response
10 Hz to 22 kHz +0/-1 dB (at 48 kHz)
Max Input Level
Combo XLR-1/4" Mic Input:+23 dBuLine Input:+16 dBu
Analog Dynamic Range
Input to Output:106 dB at Unity Gain
I/O Impedance
Combo XLR-1/4" Line/Mic Input:5 Kilohms (Unbalanced)10 Kilohms (Balanced)1/4" TRS Hi-Z Input:1 Megohm (Unbalanced)2 Megohms (Balanced)1/4" TRS, RCA Line Input:10 Kilohms (Unbalanced)1/4" TRS, XLR Line Output:50 Ohms (Balanced/Unbalanced)RCA Line Output:1 Kilohm1/4" TRS Headphone Output:40 Ohms
Noise Floor
-92 dB A-Weighted
THD+N
Mic Input to Analog Output:0.005% at +20 dB Gain (0 dBu)
Signal Generator
No
Analog Inputs
16x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line/Hi-Z Input1x Stereo RCA Coaxial Unbalanced Line Input (1 Stereo Pair)
Analog Outputs
2x XLR 3-Pin Balanced Main/Bus Output6x 1/4" TRS Balanced/Unbalanced Aux Send1x Stereo RCA Coaxial Unbalanced Stereo Control Room/Monitor Output (1 Stereo Pair)1x 1/4" TRS Headphone Output
Phantom Power
+48 V (Selectable on Individual Inputs)
Digital I/O
1x RJ45 Ethernet (Control, 1 Gb/s)1x RJ45 Ultranet (I/O)
MIDI I/O
1x MIDI 5-Pin In1x MIDI 5-Pin Out
USB I/O
1x USB-B 2.0 (Audio Playback, Control, Multitrack Record)1x USB-A (Audio Playback, Recording)
USB I/O Capacity
18x Input / 18x Output
Expansion Ports
No
Wireless
No
External Display I/O
No
Max Multitrack Recording
18 Tracks
Media Support
USB Drive
OS Compatibility
Computer: macOS / WindowsMobile: Android/iOS
Mobile Device Compatibility
iPadAndroid Tablet

Power

Input Power
100 to 240 VAC, 50 / 60 Hz

Physical

Rack Mountable
No
Operating Conditions
41 to 104°F / 5 to 40°C
Dimensions
16.1 x 14.1 x 4.3" / 40.9 x 35.8 x 10.9 cm
Weight
7.1 lb / 3.2 kg
Package Weight
10.52 lb
Box Dimensions (LxWxH)
18.25 x 16.63 x 5.7"

Specification Notes

Line 01
Key Specs
Line 02
Mixer
Line 03
Signal Processing
Line 04
Digital Audio
Line 05
Performance
Line 06
Connectivity
Line 07
Recording
Line 08
Compatibility
Line 09
Power
Line 10
Physical
Line 11
Packaging Info
