WLA-112 Wharfedale Pro

12″ coaxial hybrid curvature array element

  • 12″ Coaxial Beyma driver
  • 450 W Continuous
  • 900 W Programme
  • 1800 W Peak
  • 4.0″ LF voice coil
  • 2.87″ HF voice coil
  • 139 dB System Peak SPL
SKU: WLA-112 Categories: , , Tag: Brand:

Description

Product description

WLA-112 is a 12″ full-range line array element from our WLA-1 System, designed for professional touring and fixed installations where power, precision and coverage consistency are key.

It features a coaxial Beyma driver paired with our exclusive EVO-Fold waveguide, delivering uniform horizontal and vertical dispersion from a single, coherent source. This advanced design eliminates phase and spacing issues common in traditional two-way systems, resulting in a smoother, more controlled sound field.

With a 4.0″ LF driver voice coil and 2.87″ high-frequency voice coil, WLA-112 handles 450 W continuous (up to 1800 W peak) and delivers a maximum SPL of 133 dB @ 1 m. Supported by dedicated FIR presets for phase-coherent response, it offers natural, detailed audio reproduction — a powerful, adaptable solution for demanding professional environments.

Specifications

Active or Passive
Passive
System Type
Array Element
Configuration
Coaxial 2-way
System Continuous Power
450 W
System Programme Power
900 W
System Peak Power
1800 W
Max SPL @ 1m
133 dB
Freq Response (+/-3 dB)
55 Hz – 20 kHz
Freq Range (-10 dB)
35 Hz – 25 kHz
Bi-amp Mode Switch
No
Bluetooth
No
IP Certification
None
Driver Brand
Beyma
LF Driver Size
12"
LF Magnet Material
Ferrite
LF Frame Material
Aluminium
LF Voice Coil Size
4"
HF Driver Type
Compression Driver
HF Voice Coil Size
2.87″
HF Diaphragm Material
Composite Titanium / Polyester
HF Exit Size
1.5″
HF Power (RE:AES2-2012)
80 W
HF Rated Impedance
16 Ω
Vertical Splay Angle Range
0°- 5° – 10° – 15°
Horizontal Splay Angle
15°
Preset Library
Yes
Input Connector
2 x 4 Pole Speaker Connector
Waveguide Type
EVO-Fold
Cabinet Type
Trapezoid
Enclosure Material
Birch Plywood
Grille Material and Finish
Powder Coated Perforated Steel
Finish
Black Tough-Tone
Handles
2 side / 2 back
Deployment
Flying, Ground, Pole
Pole Mount
35 mm Dual Angle -2.5° / +7.5°
Brackets Included
Yes
Rigging
Yes
Integral Rigging
3 Points
Nominal Coverage (H x V)
100° x System dependant
Sensitivity 2.83 V / 1 m
101 dB
System Rated Impedance
8 Ω
Crossover Frequency
1.2 kHz
Recommended HPF = BW 18 dB/OCT.
30 Hz
Transformer (T)
No
Included Accessory
User Manual
Unpacked - Front Height (mm)
332
Unpacked - Rear Height (mm)
246
Unpacked - Width Front (mm)
566
Unpacked - Width Rear (mm)
566
Unpacked - Depth (mm)
465
Packed - Height (mm)
676
Packed - Width Front (mm)
425
Packed - Width Rear (mm)
425
Packed - Depth (mm)
555
Weight - Nett (kg)
28.5
Weight - Gross (kg)
31
