ARTEC-S15A DAS Audio

RM17,500.00

ARTEC-S15A-230

SPL Max: 134 dB
Dispersion: Omnidirectional
Weight: 31,0 kg ( 68,3 lb )

SKU: ARTEC-S15A Categories: Professional Sound, Speakers, Subwoofer Tag: DAS Audio Brand: DAS Audio

Description

Product description

Powered, 1000 W, 15″, band-pass subwoofer, 230 V, black

The Artec-S15A is a powered subwoofer system designed to provide extended bass response for the Artec-full range cabinets. A 2000 W peak Class D amplifier drives a D.A.S. 15SX bass loudspeaker. The 15SX loudspeaker incorporates a 4″ voice coil for high power handling and output. The subwoofer system includes two balanced inputs with stereo filtered output connections for Artec-satellite systems. The variable LPF ranges from 100 Hz 138 Hz.

ARTEC-S15A-115

Powered, 1000 W, 15″, band-pass subwoofer, 115 V, black

ARTEC-S15A-W-230

Powered, 1000 W, 15″, band-pass subwoofer, 230 V, white

ARTEC-S15A-W-115

Powered, 1000 W, 15″, band-pass subwoofer, 115 V, white

Performance

Frequency Range (-10 dB)

45 Hz -138 Hz

Maximum Peak SPL at 1 m

134 dB

Electronics and Connectors

Nominal Amplifier Power (continuous)

1000 W

Nominal Amplifier Power (peak)

2000 W

Input Type

Balanced

Input Impedance

20 kohms

Input Sensitivity

1.95 V (+8 dBu)

Audio Signal Input Connector

2 x Female XLR

Audio Signal Loop Thru Connector

2 x Male XLR

AC Input Connector

powerCon NAC3FCA

AC Output Connector

powerCON NAC3FCB

Current Draw 230 V / 115 V

-/4.0 A

Enclosure

Enclosure Construction

Birch Plywood

Enclosure Geometry

Rectangular

Rigging

M10 Rigging Points

Finish

ISO-flex Paint

Color

White

Dimensions ( H x W x D )

515 x 465 x 585 mm20,3 x 18,3 x 23,0 in

Net Weight

31,0 kg ( 68,3 lb )

Components

LF Driver

15LXN

Shipping

Carton Dimensions ( H x W x D)

580 x 510 x 632 mm22,8 x 20,1 x 24,9 in

Shipping Weight

37,0 kg ( 81,6 lb )
