ART 935-A RCF

RM7,888.00

PROFESSIONAL ACTIVE SPEAKER

  • Up to 133 dB Sound Pressure Level
  • 2100W Class-D Bi-Amplification
  • 45-20000 Hz linear frequency response
  • 3″ Titanium/Neodymium Compression Driver
  • 15″ Woofer
  • FiRPHASE zero degrees phase technology
  • Bass Motion Control woofer excursion management
SKU: ART 935-A Categories: , , Tag: Brand:

Description

Product description

ART 935-A is masterfully engineered to deliver stellar audio performance and versatility for intensive audio applications. The combination of a 3″ titanium/neodymium compression driver, 15″ woofer, two-channel 2100W amplifier, and the constant directivity True Resistive Waveguide produces coherent 100° x 60° coverage for the listening area with up to 133 dB SPL, distortion-free sound. Merging RCF proprietary FiRPHASE and Bass Motion Control DSP processing, perfectly tuned for each model, the audience will experience absolute clarity and deep, powerful bass response. The sleek cabinet uses a special polypropylene composite material with an M-brace internal reinforcement, making it easy to carry and secure to install on a pole, flown-, wall-, or truss-mounted using the multiple rigging points available.

Specifications

Acoustical specifications
Frequency Response
Max SPL @ 1m
133 dB
Horizontal coverage angle
100°
Vertical coverage angle
60°

Specification Notes

Line 01
45 Hz - 20000 Hz
Line 02
Input/Output section
Line 03
Protections
Line 04
Thermal, RMS
Line 05
Limiter
Line 06
Soft Limiter
Line 07
Controls
Line 08
Cooling
Line 09
Convection
Line 10
Connections
Line 11
VDE
Line 12
Standard compliance
Line 13
Safety agency
Line 14
CE compliant
Line 15
Physical specifications
Line 16
Grille
Line 17
Steel
Line 18
Color

Transducers

Compression Driver
1 x 1.4'' neo, 3.0'' v.c
Woofer
1 x 15'', 3.0'' v.c
Input signal
bal/unbal
Input connectors
XLR, Jack
Output connectors
XLR
Input sensitivity
-2 dBu/+4 dBu

Processor section

Crossover Frequencies
800Hz
Linear, Boost, Stage, Volume
Power section
Total Power
2100 W Peak
High frequencies
700 W Peak
Low frequencies
1400 W Peak
Cabinet/Case Material
PP Composite
Hardware
1 x M10 Top, 1 x M10 each side
Handles
1 Top , 1 each side
Pole mount/Cap
35 mm insert
Black
Size / Weight
Height
717 mm / 28.23 inches
Width
415 mm / 16.34 inches
Depth
410 mm / 16.14 inches
Weight
24.6 kg / 54.23 lbs

Shipping information

Package Height
760 mm / 29.92 inches
Package Width
475 mm / 18.7 inches
Package Depth
470 mm / 18.5 inches
Package Weight
28.4 kg / 62.61 lbs
