ART 915-AX RCF

RM7,475.00

PROFESSIONAL ACTIVE BLUETOOTH® SPEAKER

  • Built-in 6-channel Digital Mixer
  • Advanced User Interface w/ touch panel and remote control
  • 1.75″ Compression Driver and 15″ Woofer
  • Up to 131 dB Sound Pressure Level
  • 2100W Class-D Bi-Amplification
  • Dual combo preamp with 48V Power and Mini-jack stereo line input
  • Bluetooth® stereo audio input, with dual speaker pairing option
  • True Resistive Waveguide, FiRPHASE, and Bass Motion Control
SKU: ART 915-AX Categories: , , Tag: Brand:

Description

Product description

ART 915-AX is a top-notch solution for any audio application, featuring 48V microphone preamps and line inputs, an internal 6-channel digital mixer with advanced DSP, Bluetooth® stereo audio input, with dual speaker pairing option. The combination of a 1.75″ compression driver, 15″ woofer, and two-channel 2100W amplifier, produces 100° x 60° constant directivity coverage for the listening area with up to 131 dB SPL, distortion-free sound. The sleek cabinet uses a special polypropylene composite material with an M-brace internal reinforcement, making it easy to carry and secure to install on a pole, flown-, wall-, or truss-mounted using the multiple rigging points available.

Specifications

Acoustical specifications
Frequency Response
Max SPL @ 1m
131 dB
Horizontal coverage angle
100°
Vertical coverage angle
60°

Specification Notes

Line 01
45 Hz - 20000 Hz
Line 02
Input/Output section
Line 03
Protections
Line 04
Thermal, RMS
Line 05
Cooling
Line 06
Convection
Line 07
Connections
Line 08
Standard compliance
Line 09
Safety agency
Line 10
CE compliant
Line 11
Physical specifications
Line 12
Grille
Line 13
Steel
Line 14
Color

Transducers

Compression Driver
1 x 1.0'', 1.75'' v.c
Woofer
15'', 2.5'' v.c
Input signal
bal/unbal
Input connectors
Combo XLR/Jack
Output connectors
XLR

Processor section

Crossover Frequencies
1600Hz
Limiter
Soft Limiter
Controls
Color touch panel, data entry/volume encoder, dedicated App for iOS and Android.

Power section

Total Power
2100 W Peak
High frequencies
700 W Peak
Low frequencies
1400 W Peak
VDE
Electronic specifications
Frequency Response
20 Hz - 20 Hz
THD+N, 20dB gain, 0dBu out
0.005% A-Weighted

Processing

Processing Channels
6
Signal Processing
24 Bit
A/D-D/A conversion
32 Bit @ 48.0 kHz
Dynamic range
110

Inputs

Mic
2
Remote Controlled Storable Gain
Yes
Gain Range
0 dB - 42 dB
Input Noise Level
-114 dBu A-Weighted
Mic Inputs Impedance
6 kohm
Low Cut
20 Hz - 400 Hz
Phantom Power +48V
Yes
Mono Line
2
Gain Selection
0 dB - 22 dB
Line Input Impedance
21 kohm
A/D Dynamic range
114 dB
Stereo Line
1
Gain Selection (2)
0 dB - 10 dB
Stereo Line Input Impedance (kOhm)
13 kohm

Outputs

Main MIX
1

Outputs specifications

Main Out Impedance
150 ohm
Main Out Level
22 dBu
D/A Dynamic Range
114 dB

Compressors

RCF Compressors
Compressors on MIC/LINE CH1 & CH2 inputs.

EQ

Input Channels EQ
2 Shelving 1
Description
3 Band EQ: High and Low band shelving, MID band peak on IN 5 Band EQ: 4 Full Parametric, 1 High Shelving and HPF 24 dB/Oct on Amplifier and MAIN output,

Internal Effects

Send Effects
1

Mastering processors

Main OUT type
MIX OUT, CROSSOVER OUT with RCF SUBWOOFERS presets, STEREO OUTPUT, CH1 LINK OUT.
Cabinet/Case Material
PP Composite
Hardware
1 x M10 Top, 1 x M10 each side
Handles
1 Top , 1 each side
Pole mount/Cap
35 mm insert
Black
Size / Weight
Height
642 mm / 25.28 inches
Width
370 mm / 14.57 inches
Depth
363 mm / 14.29 inches
Weight
19.5 kg / 42.99 lbs

Shipping information

Package Height
685 mm / 26.97 inches
Package Width
430 mm / 16.93 inches
Package Depth
423 mm / 16.65 inches
Package Weight
23 kg / 50.71 lbs
