ART 735-A MK5 RCF

RM9,513.00

ART 745-A MK5

133 dB Max SPL
1400 WATT 2-way peak power
90° x 60°, Wide dispersion constant directivity horn
Innovative DSP Processing
4″ Compression Neodymium Driver with Titanium diaphragm
15″ Neodymium Woofer
FiRPHASE Technology
XBOOST Low Frequencies Enhancer

SKU: ART 735-A MK5 Category: Professional Sound Tag: RCF Brand: RCF

Description

Product description

ACTIVE TWO-WAY SPEAKER

The ART 745-A MK5 is the flagship speaker in its category. The titanium dome, 4.0″ voice coil neodymium compression driver offers a unique vocal clarity and sound projection. The 15″ neodymium woofer offers an extremely linear response and a precise, deep low frequency control. The transducers are produced using the most advanced assembly technologies. The amplifier delivers 1400 watts and is controlled by a DSP that takes care of crossover, equalisation, phase control, soft limiting and speaker protections

Specifications

Acoustical specifications

Frequency Response

Max SPL @ 1m

133 dB

Horizontal coverage angle

90°

Vertical coverage angle

60°

Specification Notes

Line 01

45 Hz - 20000 Hz

Line 02

Input/Output section

Line 03

Protections

Line 04

Thermal, RMS

Line 05

Limiter

Line 06

Soft Limiter

Line 07

Controls

Line 08

Cooling

Line 09

Convection

Line 10

Connections

Line 11

VDE

Line 12

Standard compliance

Line 13

Safety agency

Line 14

CE compliant

Line 15

Physical specifications

Line 16

Grille

Line 17

Steel

Line 18

Color

Transducers

Compression Driver

1 x 1.4'' neo, 4.0'' v.c

Woofer

1 x 15'' neo, 3.5'' v.c

Input signal

bal/unbal

Input connectors

XLR, Jack

Output connectors

XLR

Input sensitivity

-2 dBu/+4 dBu

Mic. Input Sensitivity

-32 dBu

Processor section

Crossover Frequencies

650 Hz

Volume, Boost, MIC/Line

Power section

Total Power

1400 W Peak

High frequencies

400 W Peak

Low frequencies

1000 W Peak

Cabinet/Case Material

PP Composite

Hardware

2 x M10

Handles

1 on top, 1 each side

Pole mount/Cap

35 mm insert

Black

Size / Weight

Height

708 mm / 27.87 inches

Width

437 mm / 17.2 inches

Depth

389 mm / 15.31 inches

Weight

18.8 kg / 41.45 lbs

Shipping information

Package Height

750 mm / 29.53 inches

Package Width

500 mm / 19.69 inches

Package Depth

440 mm / 17.32 inches

Package Weight

22 kg / 48.5 lbs
