ART 732-A MK5 RCF

RM6,050.00

ACTIVE TWO-WAY SPEAKER

131 dB Max SPL
1400 WATT 2-way peak power
90° x 60°, Wide dispersion constant directivity horn
Innovative DSP Processing
3,0″ Titanium diaphragm Compression Driver.
12″ Woofer
FiRPHASE Technology
XBOOST Low Frequencies Enhancer

SKU: ART 732-A MK5 Category: Professional Sound Tag: RCF Brand: RCF

Description

Product description

The ART 732-A is a unique speaker in its category. The titanium dome, 3.0″ voice coil neodymium compression driver offers a unique vocal clarity and sound projection. The 12″ woofer offers an extremely linear response and a precise, deep low frequency control. The transducers are produced using the most advanced assembly technologies. The amplifier delivers 1400 watts and is controlled by a DSP that takes care of crossover, equalisation, phase control, soft limiting and speaker protections.

Specifications

Acoustical specifications

Frequency Response

Max SPL @ 1m

131 dB

Horizontal coverage angle

90°

Vertical coverage angle

60°

Specification Notes

Line 01

50 Hz - 20000 Hz

Line 02

Input/Output section

Line 03

Protections

Line 04

Thermal, RMS

Line 05

Limiter

Line 06

Soft Limiter

Line 07

Controls

Line 08

Cooling

Line 09

Convection

Line 10

Connections

Line 11

VDE

Line 12

Standard compliance

Line 13

Safety agency

Line 14

CE compliant

Line 15

Physical specifications

Line 16

Grille

Line 17

Steel

Line 18

Color

Transducers

Compression Driver

1 x 1.4'' neo, 3.0'' v.c

Woofer

1 x 12'', 2.5'' v.c

Input signal

bal/unbal

Input connectors

XLR, Jack

Output connectors

XLR

Input sensitivity

-2 dBu/+4 dBu

Mic. Input Sensitivity

-32 dBu

Processor section

Crossover Frequencies

700 Hz

Volume, Boost, MIC/Line

Power section

Total Power

1400 W Peak

High frequencies

400 W Peak

Low frequencies

1000 W Peak

Cabinet/Case Material

PP Composite

Hardware

2 x M10

Handles

1 on top, 1 each side

Pole mount/Cap

35 mm insert

Black

Size / Weight

Height

637 mm / 25.08 inches

Width

387 mm / 15.24 inches

Depth

363 mm / 14.29 inches

Weight

17.8 kg / 39.24 lbs

Shipping information

Package Height

680 mm / 26.77 inches

Package Width

440 mm / 17.32 inches

Package Depth

420 mm / 16.54 inches

Package Weight

20.6 kg / 45.42 lbs
