ACTION-S18A DAS Audio

RM10,300.00

Powered, 600 W, 18″, bass-reflex subwoofer, black

SPL Max: 134 dB
Dispersion: Omnidirectional
Weight: 42,5 kg ( 93,7 lb )

SKU: ACTION-S18A Categories: Professional Sound, Speakers, Subwoofer Tag: DAS Audio Brand: DAS Audio

Description

Product description

ACTION-S18A is a high-power active subwoofer system that incorporates a 1500 W peak amplifier and single 18FW4 speaker with a 3″ coil and 20 mm winding depth, double layer and sandwich to boost system power, as well as a new forced convection circuit that that works to reduce the effects of voice coil heating.

As part of our company culture, all our systems are developed under a single philosophy: to deliver the highest possible quality in terms of both materials and overall system design. In the ACTION-500 series we use the same birch plywood as our touring systems for a tight, natural warm sound found nowhere else on the market.

Performance

Frequency Range (-10 dB)

35 Hz -125 Hz (variable LPF)

Maximum Peak SPL at 1 m

134 dB

Electronics and Connectors

Nominal Amplifier Power (continuous)

750 W

Nominal Amplifier Power (peak)

1500 W

Input Type

Balanced

Input Impeadance

20 kohms

Input Sensitivity

1.95 V (+8 dBu)

Audio Signal Input Connector

2 x Female XLR

Audio Signal Loop Thru Connector

1 x Male XLR

Control

DAScontrol™

AC Input Connector

IEC

Current Draw 230 V / 115 V

1.4 A/2.8 A

Enclosure

Enclosure Construction

Birch Plywood

Enclosure Geometry

Rectangular

Rigging

M10 Rigging Points

Finish

ISO-flex Paint

Color

Black

Dimensions ( H x W x D )

720 x 545 x 660 mm28,3 x 21,5 x 26,0 in

Net Weight

42,5 kg ( 93,7 lb )

Components

LF Driver

18FW4

Shipping

Carton Dimensions ( H x W x D)

795 x 595 x 690 mm31,3 x 23,4 x 27,2 in

Shipping Weight

45,5 kg ( 100,3 lb )
