AC01 SC&T

RM327.00

Analog/Digital Bi-directional Audio Converter

  • Supports digital and analog audio bi-directional conversion.
  • Built-in RCA, optical, and coaxial audio interfaces.
Category: Tag: Brand:

Description

Product description

AC01 is a bi-directional audio converter that can converts analog to digital audio signal or the other way around. Able to use optical or coaxial audio interface for audio input/ output. and can also split an audio signal into 2 via these 2 audio interfaces at the same time.

Support

Audio Sampling Rate
Analog to Digital Audio up to 48KHz
Digital to Analog 32K to 96KHz

Ports & Interfaces

Audio Input
3 x RCA, 1 x TOSLINK
Audio Output
3 x RCA, 1 x TOSLINK
Setting Switch
1 x Slide Switch

Power

Power Supply
5V 1A
Power Consumption
80mA (Typical), 110mA (Max)

Ambient Temperature

Operation
0 to 55℃
Storage
-20 to 85℃
Humidity
up to 95%

Physical Characteristic

Dimension
108 x 76 x 27mm
Weight
90g
